Electronic scale control
Stops the fill automatically when the target weight is reached.
Semi-automatic filling machines
Semi Automatic Diaphragm Pump Filling Machine
Bench‑friendly diaphragm‑pump filler with built‑in weighing to improve accuracy. Ideal for cosmetics, shampoos and foamy or solvent‑based liquids.
- Electronic scale control
- Diaphragm pump
- 110/220 V operation
- Adjustable nozzle height
Key features
Built for practical production use.
Diaphragm pump
Handles foamy liquids and solvents with stable flow.
110/220 V operation
≈1100 W power; plug‑and‑fill convenience.
Adjustable nozzle height
Accommodates a wide range of bottle sizes.
Auto/Manual modes
Foot pedal or timed/weight cycle.
Compact build
Small footprint for labs or benchtops.
Technical information
Specifications.
Performance varies by product, container and setup. Ask for a timed trial or specification review.
| Model | LUDP432W (typical) |
|---|---|
| Pump type | Diaphragm pump |
| Power | ≈1100 W |
| Supply | AC 110/220 V, 50–60 Hz |
| Controls | Microcomputer + electronic scale |
| Trigger | Foot pedal / auto cycle |
| Suitable liquids | Solvent, perfume, shampoo, cosmetics, edible oil |
| Bottle window | Adjustable by lift post |
| Nozzles | 1–2 (model‑dependent) |
| Accuracy | High (weight‑controlled) |
| Flow | High‑flow capability (model‑dependent) |
| Options | Anti‑drip nozzle tips |
Applications
Typical uses.
Cosmetics & personal care
Shampoo, lotion, skincare toners.
Solvents & lab
Alcohols and compatible chemicals.
Food & oil
Edible oils and low‑particulate liquids.
What is included
Specification, machine supply and support.
- Diaphragm pump base
- Integrated weighing device
- Nozzle and foot pedal
- User manual
